【Processing Capacity】0.65–185 t/h
【Max. Feed Size】<25 mm
【Discharge Size】0.074–0.89 mm
【Type】Overflow ball mill, grate-discharge ball mill
【Advantages】Long design service life, low maintenance requirements, capable of grinding ore to a uniform nano-scale, and high processing capacity.
【Services】24-hour quotation, custom parts, process flow design and optimization, one-year warranty, on-site installation.
Advantages
The ball mill is a well-known ore grinding machine widely used in the mining, construction, and aggregate industries. We provide global services including design, manufacturing, installation, and free operational training. 【Types】Classified by discharge method: overflow and grate-discharge; by grinding conditions: wet and dry grinding; by grinding media: … 【Wet Grinding】Suitable for gold, chromium, tin, tantalum-niobium, tantalite, quartz sand, lead, pebbles, etc. 【Dry Grinding】Suitable for cement, construction stone, power generation, etc. 【Grinding Media Balls】Steel balls, manganese balls, chrome balls, ceramic balls, etc. 【Common Steel Ball Sizes】40mm, 60mm, 80mm, 100mm, 120mm. 【Ball Mill Liners】Natural rubber plates, manganese steel plates; customizable thickness (50–130mm). 【Features】1. High-efficiency grinding technology with wide application. 2. Long service life and low maintenance costs. 3. High level of automation. 4. Capable of continuous operation. 5. Quality assurance, safe operation, and energy efficiency. Ball mills are typically used in conjunction with other crushers (such as jaw crushers and cone crushers) to reduce ore particles to fine and ultra-fine sizes. They can operate under either dry or wet grinding conditions. Contact us to learn more about crushers and grinding mills! 【Ball Mill Components】Feed and discharge systems, shells, gears, motors, reducers, bearings, bearing housings, frames, liners, grinding media (steel balls), etc. Please contact our overseas offices to purchase ball mill parts and wear components or to arrange a site visit.
【Ball Mill Working Principle】A high-energy ball mill is a grinding device used to reduce ores and other materials to sizes ranging from 25 mesh to ultra-fine powder. Primarily used in the mineral processing industry, it can operate in either open-circuit or closed-circuit modes. Ball milling is a process that grinds material to a uniform, controlled final particle size, typically utilizing manganese, iron, steel, or ceramic balls as the grinding media. Preliminary processing is handled by single- or multi-stage crushing and screening equipment, such as rod mills, semi-autogenous (SAG) mills, jaw crushers, and cone crushers.
【Ball Mill Manufacturer】With over 35 years of technical expertise, we design and manufacture heavy-duty, scientific-grade ball mills for industrial and laboratory applications, characterized by long service lives and low maintenance requirements. We also offer portable ball mills designed for mobile mineral processing plants. Interested in ball mill pricing or the investment cost for a crushing plant? Contact us today!
Please refer to the ball mill PDF for detailed technical drawings.
【Services】Ball mill design, material testing, grinding circuit design, and on-site installation. Ball mills are often used in conjunction with other crushers, such as jaw crushers and cone crushers. Contact us for more information on crushers and ore mills, as well as comparisons between SAG mills and ball mills, or rod mills and ball mills.
